FS100 Flow Straightener
- Straightening vanes to generate optimum flow profiles
- Requiring only 1.5 straight pipe diameters upstream and 0-0.5 downstream
- Compatible with line sizes 6” – 8”
- Epoxy-coated carbon steel body; all stainless available
Propeller Flow Meters
Advanced Flow Straightening with Propeller Technology
Farmers, irrigation dealers and water district engineers will find the McCrometer McPropeller Meter and the Flow Straightener are the ideal solution for water metering programs in agriculture and turf irrigation. The McPropeller’s advanced design delivers highly accurate liquid flow measurement in a rugged space-saving design that reduces installation costs, offers long-life and requires minimal maintenance.
The Flow Straightener provides breakthrough flow straightening technology that virtually eliminates the upstream / downstream straight pipe runs typically required in existing or new flow meter applications.
Requiring only 1.5 straight pipe diameters upstream and 0-0.5 downstream, the FS100 Flow Straightener when installed with the McPropeller slashes typical installation piping and labor costs by more than 50 percent, which makes it the right fit in both retrofit and brand new installations.
Shop
All Propeller Flow Meters
FS200 Flow Straightener
- Straightening vanes to generate optimum flow profiles
- Requiring only 1.5 straight pipe diameters upstream and 0-0.5 downstream
- Compatible with line sizes 10” – 12”
- Epoxy-coated carbon steel body; all stainless available
McPropeller
- Available with mechanical register, digital FlowCom™, and FlowConnect™ telemetry unit
- Instantaneous flowrate indicator
- 150PSI, ±2% accuracy, ±1% over reduced range
- Epoxy-coated carbon steel body; all stainless available
- 2” – 96” line sizes available
Hach Water Specialties
- Available with mechanical register, digital FlowCom™, and FlowConnect™ telemetry unit
- ±2% accuracy
- Output options include 4-20mA, AMI, and pulse
- Custom lay lengths available
- NSF approved
- 140 ° F standard, higher temps available
What Applications Benefit from FS100 Flow Straightener?
- Agriculture and Irrigation
- Fire Protection Agencies
- Drinking Water Treatment
- Drinking Water Distribution
- Cooling Water
- Mining, Metals, and Mineral Processing
- Power Generation
Frequently Asked Questions
Fluid flowing through a pipe turns a propeller. Those turns, or revolutions, equate to flow rate and volume over time. The speed of the propeller revolutions correlated with the inside diameter of the pipe, calculate flow rate and totalization. Totalization and flow rate are indicated on a meter’s register.
Propeller meters are often used in agriculture and turf applications as well as municipal water but can also be found in certain industrial applications as well.
McCrometer offers two brands of propeller meters, the McPropeller and the Water Specialties flow meters. Both meters offer many configurations including saddle-style, top-plate, tube-style, reverse flow, and more.
